Innovative Design
Hydrophilic acrylic injectable IOLs with undulating haptics and posterior haptic angulation
Rayner Sulcoflex Pseudophakic Supplementary IOLs are designed to be implanted in the ciliary sulcus to correct any residual post-operative refractive errors following the primary implantation of a conventional IOL in the capsular bag*.
* An iridotomy/iridectomy may be necessary.
Indications1, 4
- Post-surgical ametropia
- Enhancement of the refractive result after RLE or PRELEX
- Enhancement of near / far vision
- Correction of pseudophakic presbyopia
- 矫正人工晶体眼术后残余散光
- 极端近视或远视
- 患者正在经历屈光改变
- 无法进行生物测量患者的屈光矫正
避免了传统的叠加晶体的潜在问题
- 独特设计的后凹面，最大限度的减少与囊袋内晶体的接触
- 减少明亮视觉的干扰
- 减少远视力散焦的干扰。
最大限度的减少两个晶体之间的接触。
降低了晶体置换的手术风险
- 手术创伤低于囊袋内植入的人工晶体
- 避免了取出纤维化的囊袋内晶体。
光学部6.5mm直径
- 最佳的视觉效果
- 降低触碰虹膜的风险
- 降低边缘眩光和闪辉。
14.0mm的全长，波浪形攀型
- 独特的波浪形攀型设计，10°攀夹角
- 卓越的居中性和旋转稳定性
- 减少了与葡萄膜接触的风险
- 降低色素剥落综合症的发生
- 光滑的波浪形攀型设计最大限度的降低了在睫状沟与其他组织的反应。
** 不规则的睫状沟解剖可能会引起术后晶体的旋转位移，充足的虹膜到晶体和晶体到晶体之间的距离
References:
- Claoué C. Clinical and Surgical Ophthalmology 2008; 26(6): 198-200.
- Nanavaty MA et al. JCRS 2009; 35(4): 663-71
Sulcoflex IOLs are supplied with a Rayner injector
- Uniquely designed loading bay with an extension "lip" to facilitate loading.
- Soft plunger tip completely fills the nozzle and offers a soft protective interface with the IOL.
- Syringe-style design for single-handed technique for smooth IOL delivery with predictable and efficient insertion, ensuring consistent IOL implantations.
- Sterile Single-Use, ready to use.
| Model Name: | Sulcoflex Multifocal Toric |
| Model Number: | 653Z |
| Power Range: |
Spherical Equivalent: -7.0 to +7.0 D (0.5 D increments) Cylinders: +1.0 to +6.0 D (0.5 D increments) |
| Optic Diameter: | 6.50mm |
| Overall Length: | 14.00mm |
| 推注系统 | |
| Injector Type: | 一次性使用，手动安装 |
| 喷嘴直径： | 2.00 mm |
| 喷嘴斜面角度： | 45° |
| 人工晶体推送方式： | 单手植入 |
| Refractive Multifocal Toric IOL | |
| 材料： | Rayacryl® 一片式亲水丙烯酸酯材料 |
| 含水量： | 26% |
| 紫外线防护： | 紫外线吸收剂 |
| 紫外线透过率： | UV 10% (380 nm) |
| 屈光指数： | 1.46 |
| 光学部形状： | Posterior concave surface |
| 非球面技术： | Anterior aspheric surface with aberration-neutral technology |
| 光学部边缘设计： | Round-edged optic |
| 襻夹角： | 10° |
| 襻形： | Posterior haptic angulation |
Not all products or offerings are approved or offered in every market and approved labelling and instructions may vary from one country to another. For country specific product information contact your local distributor or email sales@rayner.com.cn.
Superflex is not approved by the FDA for use or distribution in the United States of America. For FDA status on C-flex please contact the Regulatory Affairs team
Rayner hold a selection of EC certificates for various products. Please contact the Regulatory Affairs team for the current version.
Rayner Supplementary Platform
For when compromise is not an option
As a cataract and refractive surgeon, achieving the best possible visual results for your patients is paramount. But sometimes, even the best patient selection and most accurate work can result in refractive surprises.
Wouldn’t it be great to have a lens that offers you more than one shot? An option that is reversible?
Rayner Sulcoflex Pseudophakic Supplementary IOLs are designed to be implanted in the ciliary sulcus to correct any residual post-operative refractve errors following the implantation of a conventional IOL in the capsular bag.
When considering an intraocular lens, what's important to you ?
Click on + below to see the features and benefits of the Rayner Supplementary Platform.
References:
3. Comparison of the uveal and capsular biocompatibility of the Rayner Centerflex (570H) vs Rayner C-flex® (570C) – three year results. Amon et al., Vienna, Austria. Presented at ESCRS, Stockholm, 2007.
Scientific Papers and Supporting Materials
Peer Review Papers
- Ferreira TB, Pinheiro J. Clinical results with a supplementary toric intraocular lens for the correction of astigmatism in pseudophakic patients. Eur J Ophthalmol. 2015 Jan 27:0
- Alio JL, Abdelghany AA, Fernández-Buenaga R. Enhancements after cataract surgery. Curr Opin Ophthalmol. 2015 Jan;26(1):50-5
- Venter JA, Oberholster A, Schallhorn SC and Pelouskova M.Piggyback intraocular lens implantation to correct pseudophakic refractive error after segmental multifocal intraocular lens implantation. J Refract Surg. 2014 Apr;30(4):234-9
- Falzon K, Stewart OG. Correction of undesirable pseudophakic refractive error with the Sulcoflex intraocular lens. J Refract Surg. 2012 Sep;28(9):614-9
- McIntyre JS, Werner L, Fuller SR, Kavoussi SC, Hill M, Mamalis N. Assessment of a single-piece hydrophilic acrylic IOL for piggyback sulcus fixation in pseudophakic cadaver eyes. J Cataract Refract Surg. 2012 Jan;38(1):155-62
- Kahraman G, Amon M. New supplementary intraocular lens for refractive enhancement in pseudophakic patients. J Cataract Refract Surg. 2010 Jul;36(7):1090-4
Trade papers:
- Amon M. Correcting Refractive Surprises Following Cataract Surgery. Cataract & Refractive Surgery Today Europe March, 2009
- Khan M, Muhtaseb M. Piggybacking With the Sulcoflex. Cataract & Refractive Surgery Today Europe June 2010
- Werner L. Sulcus add-on intraocular lenses: Background and in vitro analyses.
- J.Steele McIntyre MD, Liliana Werner MD et al. Sulcoflex Pseudophakic Supplementary IOLs” Roundtable Supplement, CRSTE, Nov/Dec 2009Link
